MJD41CT4G 100V 41A NPN Darlington Power Tab MOSFET Low Vce(sat) High Gain Fast Switching Built-in Clamp Diode TO-220 Package for Easy Mounting

MJD41CT4G 100V 41A NPN Darlington Power Tab MOSFET Low Vce(sat) High Gain Fast Switching Built-in Clamp Diode TO-220 Package for Easy Mounting

Features

•Lead Formed for Surface Mount Applications in Plastic Sleeves (No Suffix)

•Straight Lead Version in Plastic Sleeves (“1” Suffix)

•Electrically Similar to Popular TIP41 and TIP42 Series

•Epoxy Meets UL 94 V−0 @ 0.125 in

•NJV Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC−Q101 Qualified and PPAP Capable

•These Devices are Pb−Free and are RoHS Compliant

Applications

Linear voltage regulators and power amplifiers

Speed/direction control for DC and stepper motors

Drivers for solenoids, high-power relays, and actuators

Inverters and Switch-Mode Power Supplies (SMPS)

Various high-current switching circuits in automotive and industrial fields

Description

1:High Power Handling: Features a 100V collector-emitter voltage (VCEO) and a 41A continuous collector current (IC), enabling it to drive high loads.

2:Darlington Configuration: Provides very high DC current gain, allowing control of large load currents with a very small base drive current, which simplifies driver circuit design.

3:Low Saturation Voltage: A typical VCE(sat) of only 1.0V at IC=20A and IB=40mA helps minimize power loss and heat generation during the on-state, improving overall efficiency.

4:Fast Switching Speed: The optimized Darlington design offers relatively fast switching performance, suitable for switch-mode power supplies, motor control, and other applications requiring frequent switching.

5:Built-in Clamp Diode: Includes an integral flyback diode that effectively suppresses reverse electromotive force (back-EMF) generated by inductive loads (e.g., motors, relay coils), protecting the transistor from voltage spikes and enhancing system reliability.

6:Robust TO-220 Package: This package offers good mechanical strength and thermal performance, facilitates the attachment of a heat sink for high power dissipation, and ensures stable operation in high-temperature environments.

7:Lead-Free & RoHS Compliant: Meets environmental regulation requirements.

INFORMATION

Drawing
