Features

■ Step-down current mode PWM (1.5 MHz) DC DC converter

■ 2% DC output voltage tolerance

■ Synchronous rectification

■ Inhibit function

■ Internal soft start

■ Typical efficiency: > 90 %

■ 1.5 A output current capability

■ Not switching quiescent current: max 1.5 mA over temperature range

■ RDS(ON) typ.150 mΩ

■ Uses tiny capacitors and inductors

■ Operative junction temp. - 30 °C to 125 °C

■ Available in DFN6D (3x3 mm) exposed pad

Applications

1. Automotive Electronics

This is its core application area, especially leveraging its AEC-Q100 qualification.

In-Vehicle Infotainment Systems: Powers displays, main control chips, audio amplifiers, etc.

Advanced Driver-Assistance Systems (ADAS): Provides core voltages for cameras, radar sensors, control units, etc.

Instrument Clusters: Powers microcontrollers and display drivers.

Vehicle Lighting Systems: Particularly LED driving.

2. Industrial & Embedded Systems

Factory Automation & Control: PLCs, I/O modules, sensor modules.

Communication Equipment: Board-level power for routers, switches, network modules.

Test & Measurement Equipment: Powers chips inside portable devices or precision instruments.

3. Consumer Electronics & Portable Devices

Smart Home Devices: Such as smart speakers, security cameras, gateways.

Portable Printers and scanning devices.

Various embedded computers and single-board computers powered by 12V or 24V power buses.

Description

The ST1S06xx is a step down DC-DC converter optimized for powering low-voltage digital core in HDD applications and, generally, to replace the high current linear solution when the power dissipation may cause an high heating of the application environment. It provides up to 1.5 A over an input voltage range of 2.7 V to 6 V. An high switching frequency (1.5 MHz) allows the use of tiny surface-mount components: as well as the resistor divider to set the output voltage value, only an inductor and two capacitors are required.

Besides, a low output ripple is guaranteed by the current mode PWM topology and by the use of low ESR SMD ceramic capacitors. The device is thermal protected and current limited to prevent damages due to accidental short circuit. The ST1S06xx is available in DFN6D (3x3 mm) package.
